Tube Tube AH
€178.95
IEEE 802.11ah sub 1 GHz outdoor AP/CPE with single Fast Ethernet and PoE support
- (1) NXP™ i.MX 6ULL SOC (ARM™ Cortex-A7, 528 MHz) equipped with 256 MB of DDR3L RAM
- (2) Newracom™ NRC7292 WiFi HaLow™ SOC (IEEE 802.11ah draft 8.0 compliant)
- (3) 32 MB of SPI NOR flash (optional 2/4/8 GB eMMC)
- (4) Ethernet with passive PoE and ESD protection (with support for optional 802.3at/af module)
- (5) Type-N antenna connector
- (6) 4x LED
Availability:
Out of stock
SKU
Tube-AH
Tube-AH is the world's first WiFi HaLow™ outdoor AP/CPE with PoE
The Tube-AH outdoor series allows building long range, ultra-low power WiFi networks in sub 1 GHz license-exempt bands, utilizing compact, mast mounted enclosure.
With powerful ARM Cortex-A7 based SOC clocked at 528 MHz, official OpenWrt and U-Boot support, up to 15 Mbps data throughput and complete SDK for the HaLow™ radio SOC, getting started with this new WiFi standard is straightforward.
| Manufacturer | Alfa Network |
|---|---|
| SKU | Tube-AH |
| EAN | 4718050308729 |
| Processor | Morse Micro MM6108 |
| System Memory | 256 Mb |
| Flash Memory | 32 Mb |
| Antenna Connector | N-Female |
| Environment | Outdoor |
| Dimensions | ⵁ46x165 mm |
